Stratco Sectional/Tilt SDO1200 motor(motor only)no rail included
Stratco Sectional/Tilt SDO1200 motor(motor only)no rail included
Couldn't load pickup availability
Stratco Sectional/Tilt SDO1200b motor
Max garage door size:16m²
Max door weight:
Max peak pulling force:
The SDO 1200B is a super quiet and stylish garage door operator that is designed for both sectional and tilt doors and provides secure and reliable operation. The motor is covered with a 5 year warranty. • Soft start, soft close - greatly reduces wear and tear on all components and reduces noise • Includes 3 remote transmitters • Motor rail - full length C-channel rail for increased strength and stability with an auto-reconnect self-lubricating trolley made of high impact fibre filled nylon (rails are available in varying lengths for different door heights) • Includes manual release cable in case of power failure • Belt tensioner - spring loaded chain tensioning system reduces noise, wear and tear by taking up excess slack in the chain or belt • User friendly controls are reliable, safe and flexible • Six core cable belt drive system is supplied as standard to make the SDO 1200B motor virtually noiseless.
TECHNICAL DATA:
DESCRIPTION | ||
---|---|---|
Input Voltage | 220V - 240V AC, 50/60Hz | |
Input power | 260 Watts | |
Rated force | 1000N | |
Push Force - Max | 1000N | |
Open/close speed | 0.15M/S /0.13M/S | |
Lamp | LED 24V DC | |
Light time | 3 mins | |
Max door area | 16m² | |
radio frequency/decoding | 433.92/rolling code |
